Bore (mm) |
20 |
|
Accuracy |
±0.5% |
|
Flow Range 1,2 ̴ 3cP Diesel, Light Oil |
120 ̴ 1,250 L/H |
|
Flow Range 10cP Heavy Oil |
20 – 1,250 L/H |
|
Max. Working Pressure |
10 kgf/cm² |
|
Hydraulic Test Pressure |
20 kgf/cm² |
|
Max. Working Temperature |
Standard : 80°C for diesel & light oil Optional : 120°C for heavy oil |
|
Flange Rating |
JIS 10 kgf/cm²FF |
|
Material – Body |
Cast Iron (FC25) |
|
Material – Rotor |
Resin |
|
Counter Unit |
Integrating pointer and integrating counter (a reset counter is also available) |
|
Flow Direction |
Right → Left |
|
Paint Color |
Munsell 1.4PB3.1 1/2″ |
